Scope of applicationThe touch screen computer dual control smoke density tester for building materia
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
The plastic smoke density tester/FTT smoke density chamber can be used to measure and describe the response of materials, products, and components to heat and flame under controlled laboratory conditions, and to measure the static smoke production of building materials under combustion or decomposition conditions.
The touch screen computer dual control smoke density tester for building materials is developed according to the technical conditions specified in the national standard GB / T8627-2007 "test method for smoke density of burning or decomposition of building materials". It is suitable for the determination of static smoke yield of building materials and their products and other materials
Design standard: GB / T8627-2007 test method for smoke density of combustion or decomposition of building materials
Standard:
GB / T8627: Test method for density of smoke from the burning or decomposition of building materials
ASTM D2843: Standard Test Method for Density of Smoke from the Burning or Decomposition of Plastics
ASTM E662: Standard Test Method for Specific Optical Density of Smoke Generated by Solid Materials
ISO 5659: Plastics — Smoke generation — Determination of optical density by a single-chamber test
1. Dual control mode, which can be controlled on the touch screen or on the computer, and the operation mode can be easily switched! (user's own computer and printer; upper computer software, router and network cable will be sent with the device)
2. A device can be operated by several computers at the same time, and several computers can be online at the same time, which can realize LAN sharing!
3. The main and auxiliary burners can rotate automatically with accurate positioning.
4. The self-developed control program can meet the requirements of various operations, records, time curves and results calculation in the test.
| Parameter | Description |
|---|---|
| Maximum smoke density (MSD) and smoke density rating (SDR) measurement | 0 - 100% continuously measurable and automatically calculated |
| Calibration error of standard filter | Not more than 3%; each equipment equipped with three standard filters for light source calibration data representation |
| Working pressure of Bunsen lamp | (210 ± 5) kPa |
| Flame application time of Bunsen lamp on sample | 4 min |
| Combustion lamp | Bunsen lamp, length 260mm, nozzle diameter 0.13mm, at a 45° angle with the smoke box |
| Photoelectric system - light source | Bulb, power 15W, working voltage 6V |
| Exhaust system | Equipped with a powerful exhaust fan to expel waste gas out of the room after the test |
| Measurement range of smoke density | 0 ~ 100% |
| Accuracy of smoke density measurement | ± 3% |
| Receiver | Silicon photocell; 0% transmittance means no light passing through, 100% transmittance means complete light passing through |
| Working pressure of main burner | 276kpa (adjustable); (optional auxiliary burner) |
| Automatic functions | Automatic timing, automatic ignition, and automatic smoke exhaust; luminous flux can be tested by linear correction in stages to improve data accuracy |
| Touch screen - dimensions | Length 11cm, width 286.11cm |
| Touch screen - resolution | 800 * 480 |
| Touch screen - communication interface | RS232, 3.3V CMOS or TTL, serial port mode |
| Touch screen - storage capacity | 1g |
| Touch screen - drive display | Uses pure hardware FPGA drive display, "zero" start time, runs upon power-on |
| Touch screen - architecture | M3 + FPGA architecture; M3 for instruction analysis, FPGA for TFT display; main controller uses a low-power processor that automatically enters energy-saving mode |
| Gas source | 95% propane gas or gas of the same purity (Note: gas source and connecting head are provided by users themselves) |
| Dimensions (L * w * h) | 740 * 500 * 900 (mm) |
It is divided into smoke box and control system;
Smoke box: on the left and right panels of the smoke box, there are power switch, safety sign switch (backlight switch), gas regulating device, and switch for controlling exhaust fan (fan switch).
· Automatic completion of the test; a variety of signals automatically collected
· Branded computer
· The printer is optional
· Voltage: 220V; Power 4KW
· Propane gas customer-owned
